8P-26.000MBS-T,VC-TCXO振蕩器,有源晶體振蕩器,物料編碼為8P-26.000MBS-T,型號為8P,頻率為26MHz,輸出為Clipped Sine Wave,精度為±2ppm,工作溫度范圍:-30℃~85℃,尺寸為1.6*1.2mm,VC-TCXO振蕩器,OSC晶振,四腳貼片晶振,1612mm晶振,石英晶體,有源晶體振蕩器,TXC晶振,晶振廠家,特點:低電源電壓,低抖動,低電平,低損耗。廣泛應用在鍵盤,鼠標,水表,電表,智能熱水器。
8P-26.000MBS-T,VC-TCXO振蕩器,有源晶體振蕩器
規(guī)格參數(shù)表 | |
型號 | 8P |
頻率 | 26MHZ |
精度 | ±2ppm |
工作溫度范圍 | -30℃-85℃ |
電壓 | 3.3V |
輸出 | Clipped Sine Wave |
8P-26.000MBS-T,VC-TCXO振蕩器,有源晶體振蕩器
物料編碼 | 描述 | 系列 | 頻率 | 輸出 | 電壓 | 精度 | 工作溫度 |
8P-52.000MBS-T | 晶振廠家 | 8P | 52 MHz | Clipped Sine Wave | 3.3V | ±2ppm | -30°C ~ 85°C |
8P-26.000MBS-T | XTAL OSC VCTCXO 26.0000MHZ SNWV | 8P | 26 MHz | Clipped Sine Wave | 3.3V | ±2ppm | -30°C ~ 85°C |
8P-26.000MCS-T | XTAL OSC VCTCXO 26.0000MHZ SNWV | 8P | 26 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
8P-26.000MDS-T | XTAL OSC VCTCXO 26.0000MHZ SNWV | 8P | 26 MHz | Clipped Sine Wave | 1.8V | ±2ppm | -30°C ~ 85°C |
8P-26.000MBG-T | XTAL OSC TCXO 26.0000MHZ SNWV | 8P | 26 MHz | Clipped Sine Wave | 3.3V | ±500ppb | -30°C ~ 85°C |
8P-26.000MCG-T | XTAL OSC TCXO 26.0000MHZ SNWV | 8P | 26 MHz | Clipped Sine Wave | 2.5V | ±500ppb | -30°C ~ 85°C |
8P-26.000MDG-T | XTAL OSC TCXO 26.0000MHZ SNWV | 8P | 26 MHz | Clipped Sine Wave | 1.8V | ±500ppb | -30°C ~ 85°C |
8P-37.400MBG-T | XTAL OSC TCXO 37.4000MHZ SNWV | 8P | 37.4 MHz | Clipped Sine Wave | 3.3V | ±500ppb | -30°C ~ 85°C |
8P-37.400MCG-T | XTAL OSC TCXO 37.4000MHZ SNWV | 8P | 37.4 MHz | Clipped Sine Wave | 2.5V | ±500ppb | -30°C ~ 85°C |
8P-37.400MDG-T | XTAL OSC TCXO 37.4000MHZ SNWV | 8P | 37.4 MHz | Clipped Sine Wave | 1.8V | ±500ppb | -30°C ~ 85°C |
8P-38.400MBG-T | XTAL OSC TCXO 38.4000MHZ SNWV | 8P | 38.4 MHz | Clipped Sine Wave | 3.3V | ±500ppb | -30°C ~ 85°C |
8P-38.400MCG-T | XTAL OSC TCXO 38.4000MHZ SNWV | 8P | 38.4 MHz | Clipped Sine Wave | 2.5V | ±500ppb | -30°C ~ 85°C |
8P-38.400MDG-T | XTAL OSC TCXO 38.4000MHZ SNWV | 8P | 38.4 MHz | Clipped Sine Wave | 1.8V | ±500ppb | -30°C ~ 85°C |
8P-52.000MBG-T | XTAL OSC TCXO 52.0000MHZ SNWV | 8P | 52 MHz | Clipped Sine Wave | 3.3V | ±500ppb | -30°C ~ 85°C |
8P-52.000MCG-T | XTAL OSC TCXO 52.0000MHZ SNWV | 8P | 52 MHz | Clipped Sine Wave | 2.5V | ±500ppb | -30°C ~ 85°C |
8P-52.000MDG-T | XTAL OSC TCXO 52.0000MHZ SNWV | 8P | 52 MHz | Clipped Sine Wave | 1.8V | ±500ppb | -30°C ~ 85°C |
8P-37.400MDS-T | XTAL OSC VCTCXO 37.4000MHZ CLIP | 8P | 37.4 MHz | Clipped Sine Wave | 1.8V | ±2ppm | -30°C ~ 85°C |
8P-38.400MCS-T | XTAL OSC VCTCXO 38.4000MHZ CLIP | 8P | 38.4 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
8P-52.000MCS-T | XTAL OSC VCTCXO 52.0000MHZ CLIP | 8P | 52 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
8P-38.400MBS-T | XTAL OSC VCTCXO 38.4000MHZ CLIP | 8P | 38.4 MHz | Clipped Sine Wave | 3.3V | ±2ppm | -30°C ~ 85°C |
8P-37.400MBS-T | XTAL OSC VCTCXO 37.4000MHZ CLIP | 8P | 37.4 MHz | Clipped Sine Wave | 3.3V | ±2ppm | -30°C ~ 85°C |
8P-38.400MDS-T | XTAL OSC VCTCXO 38.4000MHZ CLIP | 8P | 38.4 MHz | Clipped Sine Wave | 1.8V | ±2ppm | -30°C ~ 85°C |
8P-37.400MCS-T | XTAL OSC VCTCXO 37.4000MHZ CLIP | 8P | 37.4 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
8P-52.000MDS-T | XTAL OSC VCTCXO 52.0000MHZ CLIP | 8P | 52 MHz | Clipped Sine Wave | 1.8V | ±2ppm | -30°C ~ 85°C |
8P26000003 | XTAL OSC TCXO 26.0000MHZ SNWV | 8P | 26 MHz | Clipped Sine Wave | 1.8V | ±2ppm | -30°C ~ 85°C |
8P26070001 | XTAL OSC TCXO 26.0000MHZ SNWV | 8P | 26 MHz | Clipped Sine Wave | 1.8V | ±2ppm | -30°C ~ 85°C |
8P26070004 | XTAL OSC TCXO 26.0000MHZ SNWV | 8P | 26 MHz | Clipped Sine Wave | 1.8V | ±2ppm | -30°C ~ 85°C |
