FP6400002,高頻晶振,無源晶振,四腳貼片晶振,物料編碼為FP6400002,型號為FP系列晶振,頻率為64MHz,精度為±30ppm,負載電容18pF,工作溫度范圍:-20℃~70℃,尺寸為7.0*5.0mm,高頻晶振,無源晶振,四腳貼片晶振,石英晶振,石英晶體諧振器,7050晶振,7050諧振器,晶振廠家,百利通亞陶晶振,臺產晶振,特點:高精度和耐熱環境性能等,適用于工業設備產品和醫療設備產品中.
FP6400002,高頻晶振,無源晶振,四腳貼片晶振
參數表
型號
FP
頻率
64MHZ
精度
±30ppm
負載電容
18pF
工作溫度
-20℃-70℃
FP6400002,高頻晶振,無源晶振,四腳貼片晶振
物料編碼 | 5070貼片晶振 | 型號 | 頻率 | 精度 | 負載電容 | 工作溫度 |
FQ2400001 | CRYSTAL24.0000MHZ10PF | FQ | 24MHz | ±30ppm | 10pF | -20°C~70°C |
FQ2400003 | CRYSTAL24.0000MHZ9PF | FQ | 24MHz | ±10ppm | 9pF | -20°C~70°C |
FQ2500002 | CRYSTAL25.0000MHZ10PF | FQ | 25MHz | ±30ppm | 10pF | -20°C~70°C |
FQ2500003 | CRYSTAL25.0000MHZ18PF | FQ | 25MHz | ±30ppm | 18pF | -20°C~70°C |
FQ2500014 | CRYSTAL25.0000MHZ12PF | FQ | 25MHz | ±30ppm | 12pF | -20°C~70°C |
FQ4800003 | CRYSTAL48.0000MHZ9PF | FQ | 48MHz | ±15ppm | 9pF | -30°C~85°C |
FQ5400001 | CRYSTAL54.0000MHZ9PF | FQ | 54MHz | ±10ppm | 9pF | -20°C~70°C |
F81200056 | CRYSTAL12.0000MHZ8PFSMD | F8 | 12MHz | ±20ppm | 8pF | -20°C~70°C |
F80400001Q | CRYSTAL4.0000MHZ8PF | F8 | 4MHz | ±70ppm | 8pF | -40°C~125°C |
F80600004 | CRYSTAL6.0000MHZ18PF | F8 | 6MHz | ±30ppm | 18pF | -20°C~70°C |
F80600005 | CRYSTAL6.0000MHZ10PF | F8 | 6MHz | ±50ppm | 10pF | -20°C~70°C |
F81200057 | CRYSTAL12.0000MHZ20PF | F8 | 12MHz | ±50ppm | 20pF | -20°C~70°C |
F81430073 | CRYSTAL14.31818MHZ20PF | F8 | 14.31818MHz | ±30ppm | 20pF | -20°C~85°C |
F81600022Q | CRYSTAL16.0000MHZ20PF | F8 | 16MHz | ±30ppm | 20pF | -40°C~85°C |
F81840011Q | CRYSTAL18.4320MHZ8PF | F8 | 18.432MHz | ±30ppm | 8pF | -40°C~85°C |
F82400024 | CRYSTAL24.0000MHZ12PF | F8 | 24MHz | ±30ppm | 12pF | -20°C~70°C |
F82500067 | CRYSTAL25.0000MHZ18PF | F8 | 25MHz | ±20ppm | 18pF | -20°C~70°C |
F82500068 | CRYSTAL25.0000MHZ12PF | F8 | 25MHz | ±30ppm | 12pF | -20°C~70°C |
F82500070 | CRYSTAL25.0000MHZ12PF | F8 | 25MHz | ±25ppm | 12pF | -20°C~70°C |
F82500071 | CRYSTAL25.0000MHZ16PF | F8 | 25MHz | ±50ppm | 16pF | -20°C~70°C |
F82500078 | CRYSTAL25.0000MHZ16PF | F8 | 25MHz | ±30ppm | 16pF | -40°C~85°C |
F83120001 | CRYSTAL31.2500MHZ15PF | F8 | 31.25MHz | ±50ppm | 15pF | -20°C~70°C |
F84000005Q | CRYSTAL40.0000MHZ8PF | F8 | 40MHz | ±50ppm | 8pF | -40°C~125°C |
FQ1600002 | CRYSTAL16.0000MHZ18PF | FQ | 16MHz | ±10ppm | 18pF | -20°C~70°C |
FQ1600005Z | CRYSTAL16.0000MHZ8PF | FQ | 16MHz | ±30ppm | 8pF | -40°C~85°C |
FQ1600007Q | CRYSTAL16.0000MHZ9PF | FQ | 16MHz | ±50ppm | 9pF | -40°C~125°C |
FQ1600009Q | CRYSTAL16.0000MHZ8PF | FQ | 16MHz | ±50ppm | 8pF | -40°C~105°C |
FQ2000002Q | CRYSTAL20.0000MHZ8PF | FQ | 20MHz | ±30ppm | 8pF | -40°C~85°C |
FF2400016 | CRYSTAL24.0000MHZ18PFSMD | FF | 24MHz | ±30ppm | 18pF | -20°C~70°C |
FF2500007 | CRYSTAL25.0000MHZ18PFSMD | FF | 25MHz | ±10ppm | 18pF | -20°C~70°C |
