FKA000018Z,高頻晶振,臺產百利通亞陶晶振,3225晶振,物料編碼為FKA000018Z，型號為FK系列晶振，頻率為100MHZ，輸出為L(zhǎng)VCMOS，電壓為1.8V，精度為±50ppm，工作溫度范圍為-40℃~85℃，尺寸為3.2*2.5mm，高頻晶振，有源晶體振蕩器，四腳晶體，SMD晶振，百利通亞陶晶振，3225振蕩器，3225貼片晶振，石英晶體振蕩器，SPXO晶振，LVCMOS晶振，差分晶振，晶振廠家，臺產進口晶振，貼片晶振，特點：小型，輕型，薄型，高性能，高精度，應用在微型錄音筆，智能點讀機，智能點讀筆，微型攝像頭等產品上。
FKA000018Z,高頻晶振,臺產百利通亞陶晶振,3225晶振
參數表
型號
FK
頻率
100MHZ
精度
±50ppm
電壓
1.8V
工作溫度
-40℃-85℃
輸出
LVCMOS
FKA000018Z,高頻晶振,臺產百利通亞陶晶振,3225晶振
| 物料編碼 | 描述 | 型號 | 有源晶振 | 輸出 | 電壓 | 精度 | 工作精度 |
| FK1600005 | XTALOSCXO16.0000MHZCMOSSMD | FK | 16MHz | CMOS | 3.3V | ±50ppm | -40°C~85°C |
| FK1840002 | XTALOSCXO18.4320MHZCMOSSMD | FK | 18.432MHz | CMOS | 3.3V | ±25ppm | -20°C~70°C |
| FK1840003 | XTALOSCXO18.4320MHZCMOSSMD | FK | 18.432MHz | CMOS | 3.3V | ±50ppm | -40°C~85°C |
| FK1920012 | XTALOSCXO19.2000MHZCMOSSMD | FK | 19.2MHz | CMOS | 1.8V | ±25ppm | -40°C~85°C |
| FK2000025 | XTALOSCXO20.0000MHZCMOSSMD | FK | 20MHz | CMOS | 3.3V | ±50ppm | -40°C~85°C |
| FK2000026 | XTALOSCXO20.0000MHZCMOSSMD | FK | 20MHz | CMOS | 3.3V | ±25ppm | -40°C~85°C |
| FK2400012 | XTALOSCXO24.0000MHZCMOSSMD | FK | 24MHz | CMOS | 3.3V | ±50ppm | -20°C~70°C |
| FK2400013 | XTALOSCXO24.0000MHZCMOSSMD | FK | 24MHz | CMOS | 3.3V | ±25ppm | -20°C~70°C |
| FK2400014 | XTALOSCXO24.0000MHZCMOSSMD | FK | 24MHz | CMOS | 3.3V | ±50ppm | -40°C~85°C |
| FK2450009 | XTALOSCXO24.5760MHZCMOSSMD | FK | 24.576MHz | CMOS | 3.3V | ±25ppm | -20°C~70°C |
| FK2500018 | XTALOSCXO25.0000MHZCMOSSMD | FK | 25MHz | CMOS | 3.3V | ±50ppm | -20°C~70°C |
| FK2500019 | XTALOSCXO25.0000MHZCMOSSMD | FK | 25MHz | CMOS | 3.3V | ±25ppm | -20°C~70°C |
| FK2500020 | XTALOSCXO25.0000MHZCMOSSMD | FK | 25MHz | CMOS | 3.3V | ±20ppm | -20°C~70°C |
| FK2500026 | XTALOSCXO25.0000MHZCMOSSMD | FK | 25MHz | CMOS | 2.5V | ±50ppm | -40°C~85°C |
| FK2500027 | XTALOSCXO25.0000MHZCMOSSMD | FK | 25MHz | CMOS | 1.8V | ±20ppm | -20°C~70°C |
| FK1200011 | XTALOSCXO12.0000MHZLVCMOS | FK | 12MHz | LVCMOS | 3.3V | ±50ppm | -40°C~85°C |
| FK0730008 | XTALOSCXO7.3428MHZLVCMOSSMD | FK | 7.3428MHz | LVCMOS | 3.3V | ±25ppm | -40°C~85°C |
| FK1200027 | XTALOSCXO12.0000MHZLVCMOS | FK | 12MHz | LVCMOS | 2.5V | ±25ppm | -40°C~85°C |
| FK1470009 | XTALOSCXO14.7456MHZLVCMOS | FK | 14.7456MHz | LVCMOS | 3.3V | ±25ppm | -40°C~85°C |
| FK2400032 | XTALOSCXO24.0000MHZLVCMOS | FK | 24MHz | LVCMOS | 5V | ±25ppm | -40°C~85°C |
| FK3070001 | XTALOSCXO30.7200MHZLVCMOS | FK | 30.72MHz | LVCMOS | 3.3V | ±25ppm | -40°C~85°C |
| FK3330007 | XTALOSCXO33.3330MHZLVCMOS | FK | 33.333MHz | LVCMOS | 3.3V | ±50ppm | -40°C~85°C |
| FK1920016 | XTALOSCXO19.2000MHZLVCMOS | FK | 19.2MHz | LVCMOS | 3.3V | ±25ppm | -40°C~85°C |
| FK0400016 | XTALOSCXO4.0960MHZLVCMOSSMD | FK | 4.096MHz | LVCMOS | 3.3V | ±50ppm | -40°C~105°C |
| FK1200035 | CRYSTALOSCILLATORSEAM3225T&R | FK | 12MHz | LVCMOS | 1.8V | ±25ppm | -40°C~85°C |
| FK2400010 | CRYSTALOSCILLATORSEAM3225T&R | FK | 24MHz | LVCMOS | 3.3V | ±50ppm | -40°C~85°C |
| FK2600019 | XTALOSCXO26.0000MHZCMOSSMD | FK | 26MHz | CMOS | 3.3V | ±50ppm | -40°C~85°C |
