Hosonic石英晶體/E3SB16E00000FE/6G視聽設備晶振/E3SB低損耗晶振，尺寸3.2*2.5mm,頻率16MHZ，臺灣鴻星晶振，臺灣貼片晶振，水晶振動子，石英貼片晶振，無源石英晶振，石英晶體諧振器，無源晶振，石英貼片晶振，四腳貼片晶振，輕薄型晶振，環保晶振，辦公自動化專用晶振，無線通訊晶振，視聽設備晶振，藍牙專用晶振，無線局域網應用晶振，小型設備專用晶振，便攜式設備晶振，網絡設備晶振，消費電子專用晶振，平板電腦晶振，具有廣泛的選擇空間.

石英晶振產品常常應用于OA（辦公自動化），AV（視聽）、藍牙和無線局域網應用，小型設備，便攜設備晶振，網絡設備等領域。Hosonic石英晶體/E3SB16E00000FE/6G視聽設備晶振/E3SB低損耗晶振.

Hosonic石英晶體/E3SB16E00000FE/6G視聽設備晶振/E3SB低損耗晶振參數表

Item Frequency Range			Type F0	E3SB
				16MHz			10 to 19.99MHz	20 to 23.999MHz	24 to 62.500MHz	60 to 114.285MHz
Mode of Vibration				Fundamental						3RD
Load Capacitance			CL	6to 20pF
Frequency Tolerance			ΔF/ F0	±10ppm,±15ppm,±30ppm(At 25℃)
EquivalentSeries Resistance			ESR	500Ωmax.			150Ωmax.	70Ωmax.	50Ωmax.	100Ωmax.
Temperature Stability			TC	±30ppm(Refer to 25℃)			±10ppm,±15ppm,±30ppm(Refer to 25℃)
Operating Temperature Range			TOPR	-20~+70℃,-30~+85℃Option
Storage Temperature Range			TSTG
Shunt Capacitance			C0	3pF max.
Insulator Resistance			IR	500MΩmin. (At 100VDC)
Drive Level			DL	100μW(200μW max.)
Aging			Fa	±2ppm max. (At 25℃,First year)
Packing Unit				3000pcs/reel
