編碼ABM8AIG-16.000MHZ-12-2-T3是一款3225mm四腳無源晶振專屬于激光雷達，美國Abracon晶振公司作為領先者，一直走在技術的最前沿，通過多年的拼搏，擁有先進的生產技術以及高端的生產設備，并針對市場推出高性價比的無源晶振，3225mm四腳貼片晶振，編碼ABM8AIG-16.000MHZ-12-2-T3，AEC-Q200合格，汽車等級1:-40°C至+125°C，汽車等級0:-40°C至+150°C(可根據要求提供)，TS16949生產線認證，可根據要求提供PPAP，密封陶瓷包裝，符合RoHS/RoHS II，無鉛，信息娛樂系統，無鑰匙進入和啟動，GPS和導航，舒適控制ADAS(高級駕駛輔助系統)，車對車通信，激光雷達(光探測和測距)車載網絡，動力總成和驅動控制，電源控制和轉換，工業控制與自動化。

編碼ABM8AIG-16.000MHZ-12-2-T3是一款3225mm四腳無源晶振專屬于激光雷達，測量電路內SMD晶體的性能可以將未知轉化為已知，從而消除這個問題。描述完整的頻率選擇網絡，包括板寄生最小化不確定性和最大限度地提高長期系統可靠性的信心。

Manufacturer Part Number  原廠編碼	Manufacturer廠家	Series型號	3225晶振	Frequency頻率	Package / Case包裝/封裝
ABM8AIG-14.31818MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	14.31818MHz	4-SMD, No Lead
ABM8AIG-14.7456MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	14.7456MHz	4-SMD, No Lead
ABM8AIG-16.000MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	16MHz	4-SMD, No Lead
ABM8AIG-16.384MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	16.384MHz	4-SMD, No Lead
ABM8AIG-18.432MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	18.432MHz	4-SMD, No Lead
ABM8AIG-19.6608MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	19.6608MHz	4-SMD, No Lead
ABM8AIG-20.000MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	20MHz	4-SMD, No Lead
ABM8AIG-22.1184MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	22.1184MHz	4-SMD, No Lead
ABM8AIG-24.000MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	24MHz	4-SMD, No Lead
ABM8AIG-24.576MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	24.576MHz	4-SMD, No Lead
ABM8AIG-25.000MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	25MHz	4-SMD, No Lead
ABM8AIG-26.000MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	26MHz	4-SMD, No Lead
ABM8AIG-27.000MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	27MHz	4-SMD, No Lead
ABM8AIG-28.63636MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	28.63636MHz	4-SMD, No Lead
ABM8AIG-30.000MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	30MHz	4-SMD, No Lead
ABM8AIG-32.000MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	32MHz	4-SMD, No Lead
ABM8AIG-33.000MHZ-12-2-T3	Abracon晶振	ABM8AIG	MHz Crystal	33MHz	4-SMD, No Lead

這些參數包括振蕩器環路的頻率精度、晶體看到的驅動電平和振蕩器的閉環增益裕度。

振蕩器環路振蕩的頻率應盡可能接近晶體的指定載頻。如果在頻域上偏離系統邊界條件太遠，可能會導致系統故障或失效。
為了達到所需的頻率精度，石英晶體必須看到等效于晶體制造時的電鍍電容設置的電路電容，如10pF, 12pF, 18pF等。

挑戰在于大多數MCU數據表沒有清楚地列出Cin和Cout的期望值;盡管它們?cè)谧罱K振蕩頻率中起著關鍵作用。限流電阻很少被使用，因?yàn)榇蠖鄶?shù)MCU嵌入式振蕩器回路不會對晶體產生過多的驅動。

easuring in-circuit crystal performance eliminates the problem by converting the unknowns into well knowns. Characterizing the complete frequencyselective network including board parasitics minimizes uncertainty and maximizes confidence in long term system reliability. These parameters include frequency accuracy of the oscillator loop, drive level seen by the crystal, and the closed-loop Gain Margin of the oscillator. The frequency at which the oscillator loop is oscillating should be as close as possible to the specified carrier frequency of the crystal. Deviating too far from the system’s boundary condition in frequency domain may result in system fault or failure. To achieve desired frequency accuracy, the crystal must see in-circuit capacitance equivalent to the plating capacitance set when the crystal was manufactured, such as 10pF, 12pF, 18pF, etc. The challenge lies in the fact that most MCU datasheets do not clearly outline the expected values for Cin and Cout; even though they play a critical role in the final oscillation frequency. The current limiting resistor is rarely engaged, since most MCU embedded oscillator loops do not present excessive drive to the crystal.
